Tshuaj pleev ib ce Ntau lawm kab Machinery Equipment Nqus Homogenizing Emulsifier

Cov lus piav qhia luv luv:

Lub high-speed homogenizer tsim los ntawm peb lub tuam txhab yog raws li lub hauv paus ntsiab lus uas nyob rau hauv qhov kev txiav txim ntawm lub high-ceev emulsification lub taub hau, cov ntaub ntawv raw yog attracted los ntawm qhov sib txawv nqaim nyob rau hauv nruab nrab ntawm lub emulsification lub taub hau, thiab muaj zog circulating dej ntws. tsim nyob rau hauv lub lauj kaub. Tsis tas li ntawd, qhov zoo thiab qhov tsis zoo ntawm lub hauv paus tis thiab lub peripheral qeeb stirring tis tsim muaj zog shear quab yuam, cuam tshuam quab yuam, thiab dispersion, cia cov ntaub ntawv raw yuav tsum tau crushed tag nrho, tov, emulsified, thiab homogenized, zoo nce khoom stability.

Qhov chaw ntawm Keeb Kwm: Gaoyou City, Jiangsu;

Nqe Nqe: EXW

Warrenty: Ib Xyoo

Pob: plywood case mus rau pob, stainless hlau tsau;

Tom qab-muag Service: engineers mus rau txawv teb chaws muaj.

Xa email rau peb Whatsapp

Product Detail

Khoom cim npe

Tshuaj pleev ib ce Ntau lawm kab Machinery Equipment Nqus Homogenizing Emulsifier

Lus Taw Qhia:

Peb yog cov chaw tsim khoom rau lub tshuab nqus tsev tov khoom ua 10 xyoo nrog lub Hoobkas raws li Jiangsu xeev. Nws yog indispensable khoom rau paste zib mu thiab yog heev pab tau kev paub cuab yeej nyob rau hauv lub Hoobkas kom hniav zoo nkauj nrog ua tiav kev ua haujlwm thiab zoo. Lub tshuab nqus tsev homogenizing emulsifier txhais tau hais tias thaum cov khoom siv nyob rau hauv lub tshuab nqus tsev, nws ua rau kev siv lub siab shear emulsifier los faib ib lossis ob peb theem mus rau lwm qhov txuas ntxiv sai thiab sib npaug. Cov ntaub ntawv yuav raug ua tiav nyob rau hauv qhov chaw nqaim ntawm stator thiab rotor los ntawm lub zog muaj zog ntawm cov lus tsa suab uas tsim los ntawm cov khoom siv tshuab. Los ntawm kev ua haujlwm ntawm hydraulic shearing, centrifugal extruding, cuam tshuam, tawg thiab turbulence rau ntau tshaj 100 txhiab lub sij hawm ib feeb, cov ntaub ntawv yuav dispersed thiab emulsified instantly thiab tusyees. Tom qab reciprocating ncig ntawm qhov zoo tsis muaj npuas yuav ua tiav.

Performance & Feature:

▲ Stepless hloov ceev yog saws thaum lub sij hawm sib tov kom qhov ceev ntawm blending kab yuav random nyob rau hauv qhov ntau ntawm 0-150m / min kom tau raws li cov kev cai sib txawv;

▲ Lub homogenizer siab heev txais kev siv tshuab los ntawm USA ROSS Company, tshwj xeeb los ntawm cov qauv tshwj xeeb thiab kev ua haujlwm zoo;

▲ Cov khoom uas tiv tauj cov ntaub ntawv yog txhua yam ua los ntawm stainless hlau. Sab hauv ntawm lub nkoj yog raug rau daim iav polishing 300MESH (qib huv si), uas yog raws li kev huv huv;

▲ Tag nrho cov txheej txheem suav nrog lub tshuab nqus tsev nqus thiab lub tshuab nqus tsev defoaming tuaj yeem ua tiav raws li lub tshuab nqus tsev yam tsis muaj kab mob ntawm tes, thiab yog li, ua kom lub neej ntev ntawm cov khoom;

▲ Cov tsos zoo nkauj thiab tsim nyog, uas siv cov cuab yeej polishing tshwj xeeb kom nws ci zoo li daim iav, ua kom pom cov yam ntxwv zoo nkauj.

Technical parameter:

Qauv	Muaj peev xwm	Homogenizer lub cev muaj zog		Agitator		Sab nraud Dimension			Tag Nrho Lub Zog		Limit Vacuum (mpa)
Qauv	Muaj peev xwm	KW	r / min	KW	r / min	Ntev	Dav	qhov siab	Chav cua sov	Hluav taws xob cua sov	Limit Vacuum (mpa)
10	10 L	0.75 ib	0-3000	0.37 ib	0-63 ib	1350	580	1200/1800 Nws	3	6	-0.09 Nws
20	20 L	0.75-1.1 Nws	0-3000	0.55 ib	0-63 ib	1400	650	1450/2000 ib	3	6	-0.09 Nws
50	50L ib	2.2- 5.5	0-3000	1.1	0-63 ib	2185 ib	2500	1920/2650 ib	9	18	-0.09 Nws
100	100 L	3-7.5 Nws	0-3000	1.5	0-63 ib	2385 ib	2600	1850/2900 Nws	13	30	-0.09 Nws
200	200 L	4-9	0-3000	2.2	0-63 ib	2685 ib	3000	2380/3240 ib	15	40	-0.09 Nws
300	300 L	4–11	0-3000	2.2	0-63 ib	3000	3400 ib	2500/3600	18	49	-0.085 Nws
500	500L	5.5- 11	0-3000	4	0-63 ib	3400 ib	3500	2900/3900 Nws	24	63	-0.08 Nws
1000	1000L	7.5- 15	0-3000	5.5	0-63 ib	3600 ib	4 200	3300/4600 Nws	30	90	-0.08 Nws
2000	2000L	11- 18.5 Nws	0-3000	7.5	0-63 ib	4 200	4800 ib	3800/5400 Nws	40	-	-0.08 Nws
